European regulations/standards

A comprehensive guide to regulations/standards to make an informed choice of the right level of protection for you.

Guidance on EN ISO 20345:2022 and EN ISO 20347:2022 standards.

The new EN ISO 20345:2022 and EN ISO 20347:2022regulations/standards have incorporated new specific and additional requirements. Some have been removed or have undergone changes. Here are the new requirements:

PL	Resistance to perforation (nonmetallic insert)
AN	Malleolus protection
PS	Resistance to perforation (nonmetallic insert)
CR	Shear resistance
C	Partially conductive footwear
SC	Toe cap abrasion resistance
A	Antistatic footwear
SR	Slip resistance (on ceramic tile floor with glycerin)
HI	Heat insulation of the bottom of the footwear
WPA	Water penetration and absorption

Most important and significant features in the EN ISO 20345:2022 standard

Slip Resistance (SR)

The previous tests regarding 'SRC' (SRA + SRB) slipping will no longer be used, the regulation/standard provides for a change in the procedure of performing the slipping test under different conditions, called 'SR'

(see table below)

Sole resistance to hydrocarbons

This requirement is optional for all safety ratings. If present you are indicated by FO in marking.

LADDER GRIP - GRIP ON RUNG LADDER (LG)

For better grip on ladder rungs, the sole shall have a construction that meets the requirements of the famice in the regulation/standard with a heel height of at least 10 mm, height of crampons present in the famice of at least 1.5 mm and an area of the famice itself, of at least 35 mm.

Resistance to perforation (P, PL, PS)

P Resistance to perforation with metal insert;

PL Resistance to perforation with non-metallic insert (test performed with Ø4.5mm nail);

PS Resistance to perforation with non-metallic insert (test performed with Ø3.0mm nail).

Water Penetration.

The additional requirement WRU (water-resistant uppers), which describes the water-repellent effect of the upper of the footwear, has been changed to WPA (Water penetration and absorption). The required upper requirements remain unchanged.

Toe abrasion resistance (SCUFF CAP)

A "Martindale" abrasion test of 8,000 cycles is prepared in order to determine toe abrasion; the toe shall not develop holes throughout its thickness.

Le Calzature per uso professionale a Norma EN ISO 20345:2011 sono contraddistinte da una “S” (dall’inglese Safety = Sicurezza) come Calzature di Sicurezza. La scarpa cosiddetta “di base” è marcata con le lettere “SB” (S = Sicurezza - “B” = Base). Questa Calzatura deve avere i seguenti requisiti minimi: • altezza del tomaio • puntale (lunghezza minima, base portante minima) • tomaia in pelle “crosta”, microfibra e similare • fodera anteriore • sottopiede • suola in qualsiasi tipo di materiale, può essere liscia • il tomaio, nella calzatura bassa, può essere aperta nella zona del tallone. Nelle Calzature “SB” non sono mai comprensivi i seguenti requisiti se non specificati dettagliatamente: • antistaticità • assorbimento di energia del tacco • impermeabilità dinamica del tomaio • suola con tasselli • fodera posteriore • tomaio idrorepellente • lamina o tessuto antiforo. Vi indichiamo qui di seguito il significato della timbratura che potrete rilevare su

Conformity marking	Name of manufacturer			Date of manufacture
CE	U GROUP S.r.l.			05/2023
European standard	Safety rating	Slip resistance requirement	Additional requirements	Product code
EN ISO 20345:2022	S3S	SR	HRO HI	00000 - XXX

In addition to the Basic Requirements there are others, as shown in the tables below, each optional requirement indicated in the product marking corresponds to a specific protection from the associated risk. For further details please refer to the use note.

SAFETY RATING SYMBOL		EN ISO 20345:2022														Requirements: EN ISO 20345:2022
		SB	S1	S2	S3	S3L	S3S	S4	S5	S5L	S5S	S6	S7	S7L	S7S	Minimum required values
	Closed heel area	0	X	X	X	X	X	X	X	X	X	X	X	X	X	Heel area must be closed
	Toe cap resistant to an impact of 200J	X	X	X	X	X	X	X	X	X	X	X	X	X	X

	Tip resistant to a compression of 15 kN	X	X	X	X	X	X	X	X	X	X	X	X	X	X

A	Antistatic footwear	0	X	X	X	X	X	X	X	X	X	X	X	X	X	Electrical resistance >100 kΩ and ≤1000 MΩ
E	Energy absorption in the heel area	0	X	X	X	X	X	X	X	X	X	X	X	X	X	Energy absorbed ≥20 J

FO	Hydrocarbon resistance of the sole	0	0	0	0	0	0	0	0	0	0	0	0	0	0	Increase in volume ≤12%

WPA	Water absorption and penetration of the upper	0	-	X	X	X	X	-	-	-	-	X	X	X	X	Absorption ≤30% Penetration ≤0.2 g

P	Resistance to perforation (with metal anti-puncture insert)	0	0	-	X	-	-	-	X	-	-	-	X	-	-	≥1100 N

PL	Resistance to perforation (with non-metallic anti-puncture insert)	0	0	-	-	X	-	-	-	X	-	-	-	X	-	A 1100 N no perforation

PS	Resistance to perforation (with non-metallic anti-puncture insert type PS)	0	0	-	-	-	X	-	-	-	X	-	-	-	X	Average drilling force ≥1100 N Single drilling force ≥950 N

CI	Cold insulation of the bottom	0	0	0	0	0	0	0	0	0	0	0	0	0	0	Temperature decrease after 30 minutes at -17 °C ≤10 °C

HI	Insulation from bottom heat	0	0	0	0	0	0	0	0	0	0	0	0	0	0	Temperature rise after 30 minutes at 150 °C ≤22 °C

C	Partially conductive footwear	0	-	-	-	-	-	-	-	-	-	-	-	-	-	Electrical resistance ≤100 kΩ
HRO	Sole contact heat resistance	0	0	0	0	0	0	0	0	0	0	0	0	0	0	No signs of melting and/or breakage

AN	Malleolus protection	0	0	0	0	0	0	0	0	0	0	0	0	0	0	Transmitted energy: average value ≤10 kN single value ≤15 kN

WR	Water resistance of the complete footwear	0	0	-	-	-	-	-	-	-	-	X	X	X	X	No water penetration

M	Metatarsal protection	0	0	0	0	0	0	0	0	0	0	0	0	0	0	Residual height after impact: size 41 and 42 ≥40.0 mm

CR	Shear resistance	0	0	-	0	0	0	-	0	0	0	-	0	0	0	Shear strength index ≥2.5
SR	Slip resistance (ceramic top coated with glycerin)	0	0	0	0	0	0	0	0	0	0	0	0	0	0	≥0.19 (heel 7°) ≥0.22 (toe 7°)

LG	Footwear suitable for ladders	0	0	0	0	0	0	0	0	0	0	0	0	0	0	Famice abrasion resistance and famice size appropriate for use on ladders

SC	Abrasion resistance of the toe cover	0	0	0	0	0	0	0	0	0	0	0	0	0	0	No through holes after 8000 abrasion cycles

SAFETY RATING SYMBOL		EN ISO 20347:2022														Requirements: EN ISO 20347:2022
		SB	S1	S2	S3	S3L	S3S	S4	S5	S5L	S5S	S6	S7	S7L	S7S	Minimum required values
	Closed heel area	0	X	X	X	X	X	X	X	X	X	X	X	X	X	Heel area must be closed
	Toe box resistant to an impact of 200J	-	-	-	-	-	-	-	-	-	-	-	-	-	-

	Tip resistant to a compression of 15 kN	-	-	-	-	-	-	-	-	-	-	-	-	-	-

A	Antistatic footwear	0	X	X	X	X	X	X	X	X	X	X	X	X	X	Electrical resistance >100 kΩ and ≤1000 MΩ
E	Energy absorption in the heel area	0	X	X	X	X	X	X	X	X	X	X	X	X	X	Energy absorbed ≥20 J

FO	Hydrocarbon resistance of the sole	0	0	0	0	0	0	0	0	0	0	0	0	0	0	Increase in volume ≤12%

WPA	Water absorption and penetration of the upper	0	-	X	X	X	X	-	-	-	-	X	X	X	X	Absorption ≤30% Penetration ≤0.2 g

P	Resistance to perforation (with metal anti-puncture insert)	0	0	-	X	-	-	-	X	-	-	-	X	-	-	≥1100 N

PL	Resistance to perforation (with non-metallic anti-puncture insert)	0	0	-	-	X	-	-	-	X	-	-	-	X	-	A 1100 N no perforation

PS	Resistance to perforation (with non-metallic anti-puncture insert type PS)	0	0	-	-	-	X	-	-	-	X	-	-	-	X	Average drilling force ≥1100 N
																Single drilling force ≥950 N
CI	Cold insulation of the bottom	0	0	0	0	0	0	0	0	0	0	0	0	0	0	Temperature decrease after 30 minutes at -17 °C ≤10 °C

HI	Insulation from bottom heat	0	0	0	0	0	0	0	0	0	0	0	0	0	0	Temperature rise after 30 minutes at 150 °C ≤22 °C

C	Partially conductive footwear	0	-	-	-	-	-	-	-	-	-	-	-	-	-	Electrical resistance ≤100 kΩ
HRO	Sole contact heat resistance	0	0	0	0	0	0	0	0	0	0	0	0	0	0	No signs of melting and/or breakage

AN	Malleolus protection	0	0	0	0	0	0	0	0	0	0	0	0	0	0	Transmitted energy: average value ≤10 kN single value ≤15 kN

WR	Water resistance of the complete footwear	0	0	-	-	-	-	-	-	-	-	X	X	X	X	No water penetration

M	Metatarsal protection	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Residual height after impact: size 41 and 42 ≥40.0 mm

CR	Shear resistance	0	0	-	0	0	0	-	0	0	0	-	0	0	0	Shear strength index ≥2.5
SR	Slip resistance (ceramic top coated with glycerin)	0	0	0	0	0	0	0	0	0	0	0	0	0	0	≥0.19 (heel 7°) ≥0.22 (toe 7°)

LG	Footwear suitable for ladders	0	0	0	0	0	0	0	0	0	0	0	0	0	0	Famice abrasion resistance and famice size appropriate for use on ladders

SC	Abrasion resistance of the toe cover	0	0	0	0	0	0	0	0	0	0	0	0	0	0	No through holes after 8000 abrasion cycles

X	= Mandatory requirement for the indicated category
0	= Optional requirement added to the mandatory ones, if shown on the marking
-	= Requirement not mandatory, check footwear stamping

The following information is indicated under the sole: - fit. On the gusset or tongue of the shoe are: - manufacturer's mark - part number - month and year of manufacture - the following markings: see CEconformity marking

SYMBOL	Test conditions	Coefficient of friction
	Condition A (heel slip inclined 7° toward the front)	≥0,31
	Condition B (heel slip inclined 7° backward)	≥0,36

SYMBOL	Test conditions	Coefficient of friction
SR	Condition A (sliding of the heel inclined 7° toward the front)	≥0,19
	Condition B (heel slip inclined 7° backward)	≥0,22

The slip resistance of the footwear has been tested under laboratory conditions. Additional testing by the user under the conditions present in the workplace may provide additional information. Field testing of the footwear is recommended to assess suitability for work.

Safety footwear EN ISO 20345:2022+A1:2024 and EN ISO 20347:2022+A1:2024: Work shoes conforming to this regulation/standard and marked '+A1:2024' attest to adaptation to the latest technical specifications related to upper breathability. This update, identified by Addendum A1:2024, introduces updated requirements and test methods aimed at ensuring improved performance in terms of comfort and moisture management for the user.

Specifically, footwear marked '+A1:2024' has passed upper breathability tests that verify:
- Water vapor permeability, measured in mg/cm²h, according to updated test methods.
- The water vapor coefficient, which evaluates the ability of the upper material to disperse sweat, according to updated test methods.

The inclusion of this marking ensures that the manufacturer has made the necessary changes to the production process and materials used, in range/assortment with the latest breathability standards.

Notified bodies issuing certificates of conformity to work shoes are required to verify compliance with the above.

Marking requirements \| distinguish "S" rated Footwear (EN ISO 20345:2022 and EN ISO 20347:2022)
SB	BASIC Requirements	Class
S1	Closed heel area + A + E	I
S2	S1 + WPA
S3	S2 + Relief sole + P
S3L	S2 + Relief sole + PL
S3S	S2 + WR
S6	S3 + WR
S7	S3L + WR
S7L	S3S + WR
S7S	Closed heel area + A + E
S4	S4 + Relief sole + P	II
S5	S4 + Relief sole + PL
S5L	S4 + sole with relief + PS
SBH	/	Hybrid Footwear

ESD: dissipative footwear, SUITABLE FOR EPA ENVIRONMENTS

These footwear are designed to allow continuous and controlled dissipation within safe values, of electrostatic charges present on the operator's body in order to protect electronic devices sensitive to electrostatic phenomena. The recommended value of resistance to ground "EPA" is ≤ to 3.5x107Ω. Consi dering that measurements are taken with the footwear worn by the user, the values obtained may vary significantly from person to person and according to environmental conditions since the electrical resistance of the human body is variable.

SLIP RESISTANCE OF THE SOLE EN ISO 20345:2022 and EN ISO 20347:2022
Marking Symbol (SR)	Conditions required by the standard
Slipresistance on ceramic tiles with water + NALS	≥ 0.19 footwear inclined toward the heel by 7°. ≥ 0.22 footwear inclined toward the toe by 7°
Slipresistance on ceramic tile with glycerin	≥ 0.31 footwear inclined toward the heel of 7° ≥ 0.36 footwear inclined toward the toe by 7°

THE MEANING OF EUROPEAN STANDARDS
EN ISO 20349:2010	Small splashes of molten metal such as those produced during welding operations and related processes
EN ISO 20344:2021	Test methodology and general requirements.
EN ISO 20345:2022	Specification of safety footwear with toe resistance to 200 J.
EN ISO 20346:2022	Specifications of protective footwear with toe resistance to 100 J.
EN ISO 20347:2022	Specifications of "Work shoes" or "professional" No specific toe resistance.

For more information: info@u-power.it
